YFW-300 THE HARD BEARING BALANCER (With end drive)
Down load:
Manual of
balancer type YFW300 Type YFW-300 fan impeller
balancing machine, the company is specifically designed for the manufacture
of fan and blowers manufacturing industry, a balance machine. This machine is
designed for the horizontal hard bearing, universal joint transmission,
digital table shows other common form. In addition to a common horizontal
hard bearing balancing machines outside of all the features
, but also the characteristics of specific fan impeller is given two
important parameters. First: The maximum balance of the rotor diameter The Y series of balancing machine , is an ideal versatile for rotors of different types .It's driven with drive shaft. The Yfw series of balancing machine is special for Fan rotor. It has a large turning diameter. It`s easy operation. Legible reading , high efficiency ,and to be suitable motor ,fan ,crank shaft machine etc.
SPECIFICATION
1. Mass of workpieces: ………………………………………… 2. Max.diameter
of workpieces: ……………………………………
Φ 3. Balancing speed: ……………………………………………………240-900 rpm 4. Min.achievable
residual unbalance(emar):……………………… 5. Unbalance reduction ratio(URR)………………………………… 85% 6.Motor rating: ………………………………………………………2.2/3.3kw
HP-16 hard bearing balancing machine computer electrical measurement instrument is a balanced machine dedicated computer: high reliable industrial computer chip circuit, direct 220VAC power supply, strong anti-interference, adaptation to unstable power supply conditions, for the unstable speed can also be measured. Software vector solution measurement data, large font digital display. Overall 4 digit display input parameters, a key indicator of static balance, can be set parameters of the data stability. The measured data can be processed and processed after shutdown: the different parameters can be transformed, and the measured results are more consistent with the actual measurement results. The operator if you need other parameters of the solution results, you can enter the corresponding parameters, the corresponding calculation results. Once again change the calculation parameters, the same can be directly obtained after the change of the calculation results. No need to boot the measurement again. Automatic (or manual) memory while driving the engine shutdown function, customer self calibration function, recovery of the factory calibration function, sensor signal line fault judgment and indication function.
|
|
